Protein Shake Vending Machine
The Intelligent Nutrient Solution Vending Machine provides automated nutrient solution dispensing with smart touchscreen control, precise dosing, and convenient payment options. It supports remote monitoring and inventory management, making it ideal for commercial and agricultural applications.
Product Introduction
Product Specification
Intelligent Nutrient Solution Vending
Basic Parameters
|
Item |
Specification |
|---|---|
|
Dimensions (H × W × D) |
2000 × 1000 × 600 mm |
|
Body Color |
Matte metal paint, optional colors available |
|
Material |
Cold-rolled steel + reinforced transparent window |
|
Mobility |
4 universal wheels with brakes and silent rubber sleeves |
|
Operation Interface |
21.5-inch capacitive touchscreen, 10-point touch, 1920 × 1080 (FHD) |
Functional Modules
Functional Modules
Module Specifications
|
Module |
Description |
|---|---|
|
Water Supply System |
Dual independent hot/cold water supply with constant temperature control; supports fast switching between hot and cold drinks. |
|
Powder Hopper |
8 independent powder channels; supports automatic measured dosing for instant powder, coffee powder, milk tea powder, etc. |
|
Robotic Arm System |
Closed-loop XYZ three-axis motion module with precise positioning; completes dosing, mixing, brewing, and cleaning. |
|
Cup Dispensing System |
2 independent cup dispensers; supports automatic cup delivery, counting, and replenishment alerts. |
|
Lid Placement System |
1 lid dispenser; automatic lid fetching, positioning, and placement with precise alignment at the cup outlet. |
|
Safety Protection |
Anti-pinch circular lifting door with a built-in infrared sensor; equipped with an RGB LED ambient light strip along the door edge. |
Electrical & Control
|
Item |
Specification |
|---|---|
|
Power Input |
AC 220 V / 50 Hz |
|
Rated Power |
Standby: ≤ 50 W; Peak: ≤ 2500 W (heating/cooling) |
|
Control Method |
Touchscreen operation + background management system (supports remote monitoring, inventory management, and fault alarms) |
|
Payment Interface |
WeChat / Alipay QR code; MDB L3 card reader (cash module optional) |
|
Networking |
4G / Wi-Fi dual-mode communication; real-time sales data synchronization |
Environmental Adaptability
|
Item |
Specification |
|---|---|
|
Operating Temperature |
0°C to 40°C |
|
Storage Temperature |
-20°C to 60°C |
|
Relative Humidity |
≤ 90% (non-condensing) |
|
Noise Level |
≤ 60 dB (during operation) |
5. Safety & Maintenance
Anti-pinch Protection: Lifting door stops automatically when blocked; meets safety
standards
Cleaning & Maintenance: Modular design; powder hoppers, water circuit and drip
tray are quickly detachable and washable
Fault Self-diagnosis: Automatic detection of water level, powder level, XYZ axis home
position and high-sensitivity photoelectric sensors; self-check on startup; automatic
shutdown with alarm in case of abnormality
